Slim Countertop Tablet Mount

Our Slim Countertop Tablet Mount addresses the need for a tablet mounting solution that takes up a minimum of space.

Available for a wide selection of current iPad, Windows, Android, and Chromebook tablets.

Request a Quote View Supported Tablets

Big impact in a small footprint

Our Slim Countertop Tablet Mount features a minimal footprint while still packing in many user-friendly features:

  • stable, permanent mount design
  • radio-transparent tablet enclosure does not block WiFi or Bluetooth signals
  • ADA compliant & easy to use for visitors of all heights
  • supports landscape or portrait orientation for maximum flexibility
View Specs
A cutout in the tablet enclosure for easy home button access.
A person holding a stylus which is mounted to the tablet head enclosure. The screen is asking for a signature.

Built to last

Designed for long-term use, the Slim Countertop Tablet Mount is a rugged mounting solution for a wide variety of public spaces:

  • scratch and fingerprint resistant
  • shatterproof thermoplastic tablet enclosure
  • heavy-duty steel mounting bracket, protected by a durable powder coat
  • non-porous surfaces that are easy to disinfect and sanitize
View Accessory Options

Branding & signage for you

Personalize the Slim Countertop Tablet Mount with your branding & a persuasive call to action:

  • printed in-house on professional, large-format UV and vinyl printers
  • variable-size printing droplet technology delivers fine details, smooth gradients, and crisp colors
  • submit your own design or have our in-house designers work with you
  • quick turn-around with top-notch quality control
View Graphic Options
A Slim Countertop with a Bezel graphic inviting visitors to interact with the screen to learn more.
A closeup of the barrel lock that secures the tablet within the enclosure.

Permanently secured

An unattended kiosk in a public space can be an obvious target. The Slim Countertop Tablet Mount kiosk is designed to prevent theft and other causes of interruption like power loss:

  • barrel lock with keyed access secures your tablet while simplifying access for staff
  • heavy-gauge steel mounting bracket is designed to be bolted directly to a counter surface for permanent installation
  • interior channel through the mounting bracket protects the tablet’s power supply

+ Specifications

Head enclosure is milled from durable ABS and HDPE thermoplastics. Base is made of steel and powder-coated for long-lasting protection.

Total dimensions of the assembled kiosk will depend on the tablet and any branding or accessories selected.

  • Kiosk mounting bracket: 9 H, 4.75 W, 4.25 D inches. Weight: 2 pounds.
  • Tablet enclosure (size will depend on the tablet selected): 10.5 - 12.875 L, 14 - 15.375 W, 1 - 1.125 D inches. Weight 3 - 3.85 pounds.

Maximum counter height for ADA compliance is 37 inches based on 12.9-inch tablet with the highest touch point of the screen at 48 inches from the floor.

Maximum mounting depth of the front mounting holes from edge of counter is 16.128 inches for landscape or 14.75 inches for portrait, based on 12.9-inch tablet to make reach depth compliant with ADA guidelines.

If you need complete dimensions for a specific configuration, please contact us.

Cabling exits through the base of the mount protects the tablet’s power supply and allows for a cordless appearance.

Mounting hardware required for permanent installation will depend on the counter surface and are not included. Mounting holes are compatible with a standard 0.25 inch bolt.

Tablet is not included and must be purchased separately.

+ Supported Tablet Models

Each of our head enclosures is made for a specific set of tablet dimensions, allowing the tablet to snap into the head for a secure fit. This kiosk enclosure is available for the following tablets:

iPad

Model numbers cited below are shown on the rear case of the iPad. If you need help identifying your iPad, click here.

Name Year Released Port(s) Model Number(s)
12.9-inch iPad Pro (6th gen) 2022 USB-C for power, data & audio A2436, A2764, A2437, or A2766
11-inch iPad Pro (4th gen) 2022 USB-C for power, data & audio A2759, A2435, A2761, or A2762
10.9-inch iPad (10th gen) 2022 USB-C for power, data & audio A2696, A2757, A2777
10.9-inch iPad Air (5th gen) 2022 USB-C for power, data & audio A2588, A2589, or A2591
12.9-inch iPad Pro (5th gen) 2021 USB-C for power, data & audio A2378, A2461, A2379, or A2462
11-inch iPad Pro (3rd gen) 2021 USB-C for power, data & audio A2377, A2459, A2301, or A2460
10.2-inch iPad (9th gen) 2021 Lightning for power & data, 3.5mm jack for audio A2602, A2603, A2604, or A2605
12.9-inch iPad Pro (4th gen) 2020 USB-C for power, data & audio A2229, A2069, or A2232
11-inch iPad Pro (2nd gen) 2020 USB-C for power, data & audio A2228, A2068, or A2230
10.2-inch iPad (8th gen) 2020 Lightning for power & data, 3.5mm jack for audio A2270, A2428, A2429, or A2430
10.9-inch iPad Air (4th gen) 2020 USB-C for power, data & audio A2316, A2324, A2325, or A2072
10.5-inch iPad Air (3rd gen) 2019 Lightning for power & data, 3.5mm jack for audio A2152, A2123, or A2153
10.2-inch iPad (7th gen) 2019 Lightning for power & data, 3.5mm jack for audio A2197, A2200, or A2198
12.9-inch iPad Pro (3rd gen) 2018 USB-C for power, data & audio A1876, A2014, or A1895
11-inch iPad Pro (1st gen) 2018 USB-C for power, data & audio A1980, A2013, or A1934
9.7-inch iPad (6th gen) 2018 Lightning for power & data, 3.5mm jack for audio A1893 or A1954
12.9-inch iPad Pro (2nd gen) 2017 Lightning for power & data, 3.5mm jack for audio A1670 or A1671
10.5-inch iPad Pro 2017 Lightning for power & data, 3.5mm jack for audio A1701 or A1709
9.7-inch iPad (5th gen) 2017 Lightning for power & data, 3.5mm jack for audio A1822 or A1823
9.7-inch iPad Pro 2016 Lightning for power & data, 3.5mm jack for audio A1673, A1674, or A1675
12.9-inch iPad Pro (1st gen) 2015 Lightning for power & data, 3.5mm jack for audio A1584 or A1652
iPad Air 2 2014 Lightning for power & data, 3.5mm jack for audio A1566 or A1567
iPad Air 2013 Lightning for power & data, 3.5mm jack for audio A1474, A1475, or A1476

Windows

If you need help identifying your Surface tablet, click here.

Name Year Released Approximate
Screen Size
Port(s) Model Number(s)
Microsoft Surface Go 4 2023 10.5" Surface Connect port for power, USB-C for data, 3.5mm jack for audio (unpublished)
Microsoft Surface Pro 9 2022 13" Surface Connect port for power, USB-C x 2 for data & audio (unpublished)
Microsoft Surface Pro 8 2021 13" Surface Connect port for power, USB-C x 2 for data, 3.5mm jack for audio (unpublished)
Microsoft Surface Go 3 2021 10.5" Surface Connect port for power, USB-C for data, 3.5mm jack for audio (unpublished)
Microsoft Surface Go 2 2020 10.5" Surface Connect port for power, USB-C for data, 3.5mm jack for audio 1901 (WiFi), (unpublished, 4G/LTE)
Microsoft Surface Pro 7 2019 12.3" Surface Connect port for power, USB-C & USB-A for data, 3.5mm jack for audio 1866 (WiFi), (unpublished, 4G/LTE)
Microsoft Surface Pro 6 2018 12.3" Surface Connect port for power, USB-A & Mini DisplayPort for data, 3.5mm jack for audio 1796 (WiFi), (unpublished, 4G/LTE)
Microsoft Surface Pro (2017) 2017 12.3" Surface Connect port for power, USB-A & Mini DisplayPort for data, 3.5mm jack for audio 1796 (Wi-Fi), 1807 (4G/LTE)
Microsoft Surface Pro 4 2015 12.3" Surface Connect port for power, USB-A & Mini DisplayPort for data, 3.5mm jack for audio 1724 (Wi-Fi), (unpublished, 4G/LTE)

Android

If you need help identifying your Samsung tablet, click here.

Name Year Released Approximate
Screen Size
Port(s) Model Number(s)
Samsung Galaxy Tab A8 2022 10.5" USB-C for power, data & audio SM-X200
Samsung Galaxy Tab S7 FE 2021 12.4" USB-C for power, data & audio SM-T733
Samsung Galaxy Tab S7 2020 11" USB-C for power, data & audio SM-T870
Samsung Galaxy Tab S6 Lite (2020) 2020 10.4" USB-C for power & data, 3.5mm jack for audio SM-P610
Samsung Galaxy Tab A 10.1" (2019) 2019 10.1" USB-C for power & data, 3.5mm jack for audio SM-T510 (WiFi); SM-T515 (3G, 4G/LTE & WiFi)
Samsung Galaxy Tab A 10.5" (2018) 2018 10.5" USB-C for power & data, 3.5mm jack for audio SM-T590 (WiFi); SM-T595 (3G, 4G/LTE & WiFi)

ChromeOS

Name Year Released Approximate
Screen Size
Port(s) Model Number(s)
Acer Chromebook Enterprise Tab 510 2022 10.1" USB-C for power, data & audio D652N or D652NL

Need an enclosure for a different tablet? We have frequently created custom enclosures for other tablets - please contact us to discuss your needs.

+ Button & Camera Access Options

Depending on the tablet chosen, precision-milled standard cutouts are available to allow access to:

  • the home button with pinhole and full access options available
  • the front-facing camera for photos and video

Custom cutouts to accommodate specific types of access, including power buttons, USB ports, and the rear-facing camera may also be available on request.

+ Graphics, Signage & Branding Options

All graphics and custom branding carry our 5-year warranty. Our Slim Countertop model can be customized with the following options.

Bezel graphic and custom powder coat finish must be applied prior to shipping.

+ Accessory Options

Extend the functionality of your tablet kiosk with the right accessory or peripheral. Our Countertop kiosk can be customized with the following options.

Don’t see what you are looking for? We also do custom integrations for a wide range of kiosk peripherals – please contact us to discuss your needs.

An external battery pack with multiple USB ports.

Battery Backup

requires compatible tablet & mounting outside the kiosk

A barcode scanner attached underneath the tablet screen for easy scanning.

Datalogic Barcode Scanner

requires compatible tablet

A 3.5mm audio jack port attached to the tablet enclosure.

External Audio Jack Access

requires compatible tablet

A plastic ethernet adapter that lets you connect your iPad to hard-wired internet.

iPad Ethernet Adapter

requires compatible tablet, 60” cable option & mounting outside of the kiosk

A pair of modules for providing power and data over ethernet to the tablet kiosk.

Low Voltage PoE for Power and/or Data

requires compatible tablet & mounting outside the kiosk

+ Large-Scale Projects & Volume Discounts

Kiosk Group is uniquely positioned to respond to the logistic challenges of large-scale projects. Our process and manufacturing capacity come together to ensure that your project is delivered on time and budget, whether you are ordering a single kiosk or several thousand.

To ensure we are providing the best possible value for every customer, we offer volume discounts starting at 10 or more kiosks. Please contact us so we can put together a formal quote and timeline based on your exact needs.

+ Shipping Details

This item ships unassembled in custom protective packaging (included in shipping costs) via FedEx. If you would prefer to receive your kiosk fully assembled or are interested in installation services, please include that with your quote request.

For larger orders, we can also offer more economical shipping options, including pallet shipping and drop-shipping to specific locations.

Tracking information will be sent once the item has shipped. We ship all kiosks with adult signature required on delivery.
